Beacon XL+
Introducing the S5 Beacon XL+, your enhanced solar-powered base camp Meshtastic receiver. Designed to anchor your off-grid communications, the S5 Beacon Device XL+ features dual high-efficiency solar panels and an enhanced antenna for extended reach. It ensures continuous operation, leveraging the sun’s power to keep you connected longer. Ideal for remote expeditions and emergency preparedness, the S5 Beacon XL+ stands as a reliable hub for your Meshtastic network, offering unrivaled connectivity and durability where it matters most.
Regular price
$189.99
Sale price
$189.99
Regular price
Unit price
Save $0.00
Beacon XL+
Product Description
Specs
User Guide
Spec5 Beacon XL+ – Solar-Powered LoRa Base StationÂ
What’s Included in the Box
- Spec5 Beacon XL+ DeviceÂ
- Dual High-Efficiency Solar PanelsÂ
- Advanced 915 MHz LoRa AntennaÂ
- USB-C Charging CableÂ
- User GuideÂ
Key Features
- Dual Solar-Powered Operation: Ensures continuous functionality with dual high-efficiency solar panels.Â
- Extended Range: Enhanced antenna provides urban range of ~1-3 miles and rural range of ~3-5 miles.Â
- Ruggedized PETG enclosure: Glycol-modified PET (PETG) is extremely rugged, and the addition of glycol prevents crystallization so it can withstand higher heat applications without warping or melting.Â
- Efficient Power Management: Equipped with 2 x 18650 batteries, offering 8 hours active and 24 hours standby battery life.
Use-Case ScenariosÂ
- Remote Expeditions: Maintain communication in off-grid locations.Â
- Emergency Preparedness: Reliable connectivity during power outages or disasters.Â
- Usage: Beacon can be use as both a handheld device or a temporary mesh extender on the ground.Â
- Outdoor Events: Facilitates coordination in large venues without relying on cellular networks.Â
Deployment
- Plug-and-Play Setup: Preconfigured for immediate use with Meshtastic firmware.Â
- Flexible Mounting Options: Suitable for various installations, including base camps and vehicles.Â
- USB-C Charging: Supports 5V charging for quick power replenishment.Â
Disclaimer
The Spec5 Beacon XL+ operates within the 915 MHz frequency band. Ensure compliance with local frequency regulations.Â
Additional Resources
- Meshtastic Organization Website: https://meshtastic.org
- Meshtastic YouTube Channel: https://www.youtube.com/meshtastic
| Case Material | PETG |
|---|---|
| DIMMS | 90 x 85 x 60 mm |
| Weight | 200g |
| MCU | 32-bit ARM® Cortex™-M4 |
|---|---|
| LORA Node Chip | NA |
| RAM | 1 MB |
| FLASH | 256 KB |
| Battery | 2 x 18650 |
|---|---|
| Battery Life | 8 Hours Active / 24 Hours Standby |
| Charging | USB-C 5 Volt |
| Solar Charging | Active: ~1-3 Day Battery Extension (Quick Charging ) |
| Antenna | 915 MHz LoRa Antenna GPS Ceramic Antenna |
|---|---|
| Frequency | 915 MHz |
| Urban Range | ~1-3 Miles |
| RuRal Range | ~3-5 Miles |
Important Device Information
Spec5 devices are configured for Meshtastic use, but additional setup may be required on your phone or personal device. Spec5 is not responsible for app installation, configuration, compatibility, or troubleshooting on user-owned devices. Please consult Meshtastic’s official guides and confirm your device meets the app’s requirements.
